GPRO X080 10GB GDDR6

Specifications

• Mfr Part Number: 32312-04-21G
• GPU: NAVI 22 Family
• Stream Processors: 2304
• Compute Units: 36
• Engine Clock: 2132 MHz
• Memory Clock: 16 Gbps
• On board Frame Buffer: 10GB/160bit GDDR6
• Bus Interface: PCI Expresss 4.0 x16
• Display Output: N/A
• External Power Connector: PCI Express 8 pin x 1
• Cooling Solution: Active Dual Fan
• Form Factor: 2.2 slot
• Board Dimension: 260(L)x 119.85(W) x 49(H)mm
• Bracket: Full Height
• Operating System: Linux Based System Only
• Packaging: Brown Box
• Reference Ethash Performance: Default ~38.05 MH/s@~165W TGP, depening on the tuning of each card, ~41.6 MH/s@~93W could be reached
• System Requirement:
  • PCI Express based PC is required with one X16 lane graphics slot available on the motherboard
  • 500W (or greater) power supply with minimum one PCIE 8 pin power connector is required
  • Minimum 8GB of system memory. Recommended 16GB or more
  • Installation software requires a keyboard, a mouse, and a display
  • A display with digital input (HDMI or DisplayPort) is required
  • Support Linux based system only
  • 64-bit operating system required
  • Requires motherboard/CPU with integrated graphics processor and at least one display output
